Planet Horizontal Toggle Clamp 230kg

The Planet Horizontal toggle clamps have the advantage of having a low profile when the handle is in the closed position, and so are most suitable for applications having a height restriction. The arm and handle geometry use opposite axis directions. They have a high holding capacity to size ratio which makes them ideal for use in a workshop environment where space is limited. With these clamps, you can make easily make jigs for woodworking tasks, such as routing and milling.Features include:Red vinyl hand grip with cushioned rib profile for improved user comfort.All body and linkage components are zinc plated to resist corrosion.Pivot points are fitted with hardened steel or stainless steel rivets to provide a long service life.Clamps with adjustable spindles are manufactured with a formed end to the arm, which captivates the spindle should it become loose during operation.The handle and arm linkages are designed to provide a smooth continuous action when the handle is opened and closed.SKU: H45Holding Force: 227KgArm Opens: 90°Handle Opens: 65°MaterialClamp: Zinc Plated Mild SteelSpindle: Neoprene Tipped SteelHandle: uPVC
